12 Appendix
12.1 Specifications
12.1.1 Environmental
Table 58: Environmental Specifications
Standard Temperature Extended Temperature
Operating Temperature 0 ◦ C to +50 ◦ C -20 ◦ C to +70 ◦ C
Storage Temperature -20 ◦ C to +70 ◦ C -30 ◦ C to +80 ◦ C
Operating Relative Humidity 90% max non-condensing
Vibration (Operating) 4.9 m/s 2 XYZ directions
Vibration (Non-Operating) 19.6 m/s 2 XYZ directions
Shock (Operating) 29.4 m/s 2 XYZ directions
Shock (Non-Operating) 490 m/s 2 XYZ directions
12.1.2 Electrical
Table 59: Electrical Specifications
Standard -V -VPT
Supply Voltage +5Vdc ±0.25V +9V to +15V +9V to +35V
Minimum Current 40mA typical
Backlight On (YG & IY) add 130mA (170mA ) typical
Backlight On (R) add 160mA (200mA) typical
Backlight On (GW & WB) add 35mA (75mA) typical
12.2 Optical Characteristics
Table 60: Optical Characteristics
Character x Lines 20 columns x 4 rows
Module Size 98.00 mm x 60.00 mm x 27.50 mm
Character Size 2.95 mm x 4.75 mm
Display Size 76.30 mm x 25.00 mm
LED Backlight Half-Life (YG & IY) 50, 000 hours typical
LED Backlight Half-Life (R) 20, 000 hours typical
LED Backlight Half-Life (GW & WB) 10, 000 hours typical
