Description Syntax Page
Initialize Horizontal Bar Hexadecimal 0xFE 0x68
Decimal 254 104
ASCII 254 “h”
30
Place Horizontal Bar
Graph Hexadecimal 0xFE 0x7C [Col] [Row] [Dir] [Length]
Decimal 254 124 [Col] [Row] [Dir] [Length]
ASCII 254 “|” [Col] [Row] [Dir] [Length]
31
Initialize Narrow Vertical
Bar Hexadecimal 0xFE 0x73
Decimal 254 115
ASCII 254 “s”
31
Initialize Wide Vertical
Bar Hexadecimal 0xFE 0x76
Decimal 254 118
ASCII 254 “v”
31
Place Vertical Bar Hexadecimal 0xFE 0x3D [Column] [Length]
Decimal 254 61 [Column] [Length]
ASCII 254 “=” [Column] [Length]
32
11.4 General Purpose Output
Description Syntax Page
General Purpose Output
Off Hexadecimal 0xFE 0x56 [Num]
Decimal 254 86 [Num]
ASCII 254 “V” [Num]
33
General Purpose Output
On Hexadecimal 0xFE 0x57 [Num]
Decimal 254 87 [Num]
ASCII 254 “W” [Num]
33
Set Startup GPO state Hexadecimal 0xFE 0xC3 [Num] [state]
Decimal 254 195 [Num] [state]
33
11.5 Display Functions
Description Syntax Page
Display On Hexadecimal 0xFE 0x42 [min]
Decimal 254 66 [min]
ASCII 254 “B” [min]
34
Display Off Hexadecimal 0xFE 0x46
Decimal 254 70
ASCII 254 “F”
34
Set Brightness Hexadecimal 0xFE 0x99 [brightness]
Decimal 254 153 [brightness]
35
Set and Save Brightness Hexadecimal 0xFE 0x98 [brightness]
Decimal 254 152 [brightness]
35
Matrix Orbital LCD2041 44
