Syntax Hexadecimal 0xFE 0x54
Decimal 254 84
ASCII 254 “T”
Description This command will turn the block cursor off.
Remembered Yes
6 Special Characters
6.1 Introduction
The LCD2041 has the ability to create four different sets of eight custom characters and save them to
internal banks of memory. Each set of eight can be recalled from memory at any time, and selected characters
can be written to the display screen. Characters and sets can be created at any time, saved for later use, and
displayed to the screen through the intuitive command structure described below.
6.2 Creating a Custom Character
Syntax Hexadecimal 0xFE 0x4E [refID] [data]
Decimal 254 78 [refID] [data]
ASCII 254 “N” [refID] [data]
Parameters Parameter Length Description
refID 1 Character reference ID (0-7).
data 8 Character data.
