7 Appendix: Specifications
7.1 Specifications
Table 16: Environmental Specifications
Standard Temperature Extended Temperature
Operating Temperature 0 ◦ C to +50 ◦ C -20 ◦ C to +70 ◦ C
Storage Temperature -20 ◦ C to +70 ◦ C -40 ◦ C to +85 ◦ C
Operating Relative Humidity 90% max non-condensing 90% max non-condensing
Table 17: Electrical Specifications
Supply Voltage 4.75 - 5.25 Vdc (optional 8 - 15 VDC)
Supply Current 11 mA typical
Supply Backlight Current 90 mA typical
Table 18: Optical Characteristics
Number of Characters 80 (20 characters by 4 lines)
Matrix format 5 x 7 with underline
Display Area 76.3 x 25.20 mm XxY
Character Size 2.95 x 4.75 mm (XxY), not including underline
Character Pitch 3.55 mm
Line pitch 5.35 mm
Dot Size 0.55 x 0.55 mm (XxY)
Dot Pitch 0.60 x 0.60 mm (XxY)
LED Backlight Life 100,000 hours typical
Color of Illumination Yellow Green
