6.6 Miscellaneous Commands
Table 14: Miscellaneous Commands
Command
Syntax
Default
Notes
Clear display
FE 58
254 88
254 ’X’
n/a
Clears screen of
text and graphics,
places text cursor
at top left.
Set contrast
FE 50 [contrast]
254 80 [contrast]
254 ’P’ [contrast]
0x80128
Sets display con-
trast.
Compen-
sates for viewing
angle.
Contrast
is a value between
0 and 255 (hex 0
to FF). Larger =
darker.
Backlight on
FE 42 [minutes]
254 66 [minutes]
254 ’B’ [minutes]
on
Backlight
will
stay on for [min-
utes]. If [minutes]
=
0
backlight
will
stay
on
permanently.
Backlight off
FE 46
254 70
254 ’F’
on
Turns off back-
light.
General purpose output off
FE 56 [gpo #]
254 86 [gpo #]
254 ’V’ [gpo #]
off
Turns
general
purpose
output
OFF.
General purpose output on
FE 57 [gpo #]
254 87 [gpo #]
254 ’W’ [gpo #]
off
Turns
general
purpose
output
ON.
Read module type
FE 37
254 55
254 ’7’
see table
This command re-
turns a 1-byte hex
value.
Matrix Orbital
LCD2041
25
