7. Appendix: Command Summary

7.1 General

The operation of the LK202-25 is controlled by a simple and consistent command set. Commands control

§ text display
§ graphics display
§ keypad interface
§ miscellaneous operating parameters

This chapter includes summary tables of all commands. Individual commands are discussed in detail in
Chapters 3 to 5 in the same sequence as in the following tables.

7.2 Issuing Commands

Commands are issued to the LK202-25 by the controller. In a test setup, commands can be issued to the
LK202-25 by means of a BASIC program, using the chr$( ) function. In the tables below, we've shown
commands in hex, ASCII and decimal form. All commands begin with the prefix character 0xFE (254
decimal). These commands are issued on the serial communications link (I

2

C or RS-232) at the currently

defined baud rate.

For example (using BASIC in a test setup), you could issue the command to clear the screen on the
LK202-25 by including the line:

PRINT#1,chr$(254);chr$(88)

in your BASIC program.

7.3 On Numbers

Like all computerized devices, the LK202-25 operates with commands and values in the form of binary
numbers. These binary numbers are arranged in 8 digit (i.e. 8 bit) groups called bytes. The decimal value
of a byte may have any value from 0 to 255.

Bytes are usually specified in either decimal or hexadecimal (base 16) form for convenience, since binary
numbers are confusing to deal with directly. Hexadecimal (hex) numbers are particularly convenient
because exactly two hexadecimal digits make up one byte, each hex digit representing 4 binary digits (4
bits) as shown here:

Binary

Hex

Decimal

Binary

Hex

Decimal

0000

0

0

1000

8

8

0001

1

1

1001

9

9

0010

2

2

1010

A

10

0011

3

3

1011

B

11

0100

4

4

1100

C

12

0101

5

5

1101

D

13

0110

6

6

1110

E

14

0111

7

7

1111

F

15
