Serial Communication Adapters Instruction Manual
5
SPECIFICATIONS
101B224-06 DM61 RS-232 Serial Adapter
COMPATIBILITY EIA-232
CONNECTORS
PC compatible 9-pin D subminiature connector (DB9) and
RJ45 (adapter to meter)
CABLE 6' (1.8 m) standard Cat5e cable provided with adapter
DISTANCE Adapter to DM61 meter: 6' (1.8 m) max; Adapter to com-
puter: 50' (15 m) max; serial interface cable not provided
POWER Powered by DM61 meter M-Link connection
STATUS
INDICATION Separate LEDs for Power (P), Transmit (TX), and
Receive (RX)
101B224-07 DM61 RS-485 Serial Adapter
COMPATIBILITY EIA-485
CONNECTORS
Removable screw terminal connector and RJ11 (adapter to
meter)
CABLE 6' (1.8 m) standard Cat5e cable provided with adapter
DISTANCE Adapter to DM61 meter: 6' (1.8 m) max; Adapter to com-
puter: 3,937' (1,200 m) max
POWER Powered by DM61 meter M-Link connection
STATUS
INDICATION Separate LEDs for Power (P), Transmit (TX), and
Receive (RX)
101B224-08 DM61 USB Serial Adapter
COMPATIBILITY USB 1.1, USB 2.0
CONNECTORS
RJ45, and USB Type B
CABLE One 6' (1.8 m) standard Cat5e cable and one 3.28’ (1.0 m)
USB A-B Male cable provided with adapter
DISTANCE Adapter to DM61 meter: 6' (1.8 m) max. USB connection:
10' (3 m) max
DRIVER Windows 98/SE, ME, 2000, Server 2003/2008, XP 32/64-
Bit, Vista 32/64-Bit, Windows 7 32/64-Bit
POWER USB Port
STATUS
INDICATION Separate LEDs for Power (P), Transmit (TX), and Receive
(RX)
