Page 33

Section 4. USB Communications

This property is stored in non-volatile memory, so it will persist when the unit
is power cycled. When this property is changed, the unit must be reset (see
Command Number 2) or power cycled to have these changes take effect.

Example Set ASCII To Keypress Conversion Type property Request (Hex):

Cmd Num

Data Len

Prp ID

Prp Value

Example Set ASCII To Keypress Conversion Type property Response (Hex):

Result Code Data Len

Data

Example Get ASCII To Keypress Conversion Type property Request (Hex):

Cmd Num

Data Len

Prp ID

Example Get ASCII To Keypress Conversion Type property Response (Hex):

Result Code Data Len

Prp Value

INTERFACE TYPE PROPERTY
Property ID:

0x10

Property Type:

Byte

Length:

1 byte

Get Property:

Yes

Set Property:

Yes

Default Value:

1 (keyboard emulation)

Description:

The value is a byte that represents the devices interface type. The value can
be set to 0 for the HID interface or to 1 for the keyboard emulation interface.
When the value is set to 0 (HID) the device will behave as described in the
HID manual. When the value is set to 1 (keyboard emulation) the device will
behave as described in the keyboard emulation manual. This property should
be the first property changed because it affects which other properties are
available. After this property is changed, the device should be power cycled
before changing any other properties.
