USB Keyboard Emulation Swipe Reader
16
Value
(Hex)
Property ID
Description
10
INTERFACE TYPE
Type of USB interface
11
ACTIVE KEYMAP
Selects which key map to uses
12
PRE CARD STRING
Pre card string
13
POST CARD STRING
Post card string
14
SS TK1 ISO ABA
Start sentinel char for track 1 – ISO/ABA
16
SS TK2 ISO ABA
Start sentinel char for track 2 – ISO/ABA
16
ES
End sentinel char for all tracks/formats
except JIS type 2
17
ES TK1
End sentinel char for track 1
18
ES TK2
End sentinel char for track 2 except JIS type
2
19
ES TK3
End sentinel char for track 3
1A
DECODE ENABLE
Enables decoding for certain formats
1B
SS JIS TYPE 2
Start sentinel char for JIS type 2
1C
ES JIS TYPE 2
End sentinel char for JIS type 2
1D
PAN NAME DATE ENABLE
Enables PAN name data format
1E
POST TK CHAR ENABLE
Enables the post track character per track
52
HOST POLL TIMEOUT
Allows USB poll timeout to be adjusted
The Property Value is a multiple-byte field that contains the value of the property. The number
of bytes in this field depends on the type of property and the length of the property. The
following table lists all of the property types and describes them.
Property Type Description
Byte
This is a one-byte value. The valid values depend on the property.
String
This is a multiple byte ASCII string. Its length can be zero to a
maximum length that depends on the property. The value and
length of the string does not include a terminating NUL character.
SOFTWARE ID PROPERTY
Property ID:
0x00
Property Type:
String
Length:
Fixed at 11 bytes
Get Property:
Yes
Set Property:
No
Description:
This is an 11 byte read only property that identifies the software part number
and version for the device. The first 8 bytes represent the part number and the
last 3 bytes represent the version. For example this string might be
“21042812D01”. Examples follow:
Example Get Software ID property Request (Hex):
Cmd Num
Data Len
Prp ID
00
01
00
Example Get Software ID property Response (Hex):
Result Code Data Len
Prp Value
00
01
32 31 30 34 32 38 31 32 44 30 31
