Section 3. Operation and Maintenance
13
1 .Observe Position
Of Jammed Card.
Back View
3 .Push Rod Until Card
Appears In Front.
Then Pull Card Out.
2 . Insert Rod Into Slot.
Reposition Until Card
Is In Notch In Rod.
Figure 3-2. Card Removal with Ejector Rod
3. Insert the Rod into the slot as shown in Figure 3-2.
4. Reposition as required until the card is in the notch.
5. Push the Rod until the card appears in the front, then, pull it out.
6. Replace the Rod as indicated in Figure 3-1.
