IntelliStripe 340, Desktop Motorized Reader

Table 1-1. Specifications

DATA FORMAT SPECIFICATIONS

Reader Configuration:

Mag-Stripe Functions
Track 1,2,3 only:

Data Format Specifications*

ISO/ANSI/AAMVA/CDL

JIS formats

ISO 7810, 7811, JIS x 6302 Type 2

* ISO (International Standards Organization), ANSI (American National Standards Institute), AAMVA,
(American Association of Motor Vehicle Administrators), CDL (California Drivers License)

JIS

(Japanese Industrial Standard)

OPERATIONAL

Card Speed:

10 IPS (25,4 cm/sec) typical

Recording Method:

Two-frequency coherent phase (F2F)

MTBF:

Electronics:

Head:

SC Contacts:

125,000 hours
1,000,000 passes (500,000 Insertion Cycles)
1,000,000 passes

ELECTRICAL

Input Voltage:

Current:

12.0 VDC

± 5%

1.5 A max
170 mA typical (with motor off)

MECHANICAL

Dimensions:

Length:

Width:
Height:

Cable Length (16051412):

Power Supply Cable Length
(64300080):

Power Cord (North American
100-240V) (P/N 71100001):

7.125” (181.0 mm)

4.56" (115.82 mm)
2.85" (72.40 mm)

6’ (1.83 m)

6’ 4” (1.93 m)

7’ 6” (2.28 m)

Weight:

Reader with Cable:

Power

Supply:

AC Cord:

2 lb 5.33oz (1.05 kg)
6.4 oz (0.2 kg)
6.4 oz (0.2 kg)
