IntelliStripe 310 Command Reference
28
NOTIFY INDICATOR CHANGE 0 TO 1 PROPERTY
Property ID: 01 (Hex)
Property Type: Dword
Power Up/Reset Value: 0
Get/Set support: Both
Description:
This property is used to control notification messages sent in response to a transport indicator
changing from a 0 to a 1 state. If the bit corresponding to an indicator is set, then a notification
message will be sent from the device to the host in response to that indicator changing from a 0
to a 1 state. The notification message will have the same syntax as the get property command
response of the indicator property. The only difference is that the message header will contain a
notification message type instead of a response message type. If more than one indicator
changes state at the same time, only one notification message will be sent that contains the state
of all the indicators.
Values:
The bits are identified by numbering the least significant bit 0 and the most significant bit
31.
Bits Indicator Description
0 Front Card
Present
If set to 1, a notification message will be sent in response to a
0 to 1 transition of the front card present indicator. If cleared
to 0, no notification will be sent.
1-2 RFU (0) Reserved for future use (Must be zero)
3 Auto Transporting If set to 1, a notification message will be sent in response to a
0 to 1 transition of the auto transporting indicator. If cleared
to 0, no notification will be sent.
4-31 RFU (0) Reserved for future use (Must be zero)
Example Set Property Request:
Field MTYP APPL CMND RC PTYP PID
Byte 1 2 3 4 5 6
Value (Hex) 00 82 01 00 01 01
Field PVAL
Byte
7 - 10
Value (Hex) 01 00 00 00 (Front Card Present)
Example Set Property Response:
Field MTYP APPL CMND RC
Byte 1 2 3 4
Value (Hex) 40 82 01 00
