Section 2. Communications
25
Property ID
P-
Value
Property Description HID
mode
KB
mode
Other
0x05 0x05 0x05 Track ID Enable Track enable / ID enable
0x07 0x07 0x07 ISO Track Mask Specifies Masking factors for ISO cards
0x08 0x08 0x08 AAMVA Track Mask
Specifies Masking factors for AAMVA
cards
0x0A - Max Packet Size The interrupt pipe’s packet size
0x0A
RS-232 Communications
(RS232 models only)
Specifies speed and parity
0x0B Activity Timeout Period
BulleT, Flash: Specifies minimum time
reader will operate in the absence of
activity (used to conserve battery life)
0x0D
Bluetooth Disconnect
Message BulleT: Specifies string to be used as
part of Bluetooth Disconnect Message
0x0D
Track Data Transmission
Delay Property Flash: specifies amount of delay until
requested Track Data is sent
0x0E Stay Powered After Swipe
BulleT, Flash: Allows reader to stay
powered after a good swipe
0x0F RF Address
BulleT, U-Finity: Specifies the RF
address used to pair the wireless dongle
and reader
0x10 0x10 0x10 Interface Type Type of interface
- 0x14 0x14 Track Data Send Flags Track data send flags
0x15 0x15 0x15 MP Flags
Enables sending of MagnePrint data
when in security level 2
- 0x16 Active Keymap Selects which key map to use
- 0x17
ASCII To Keypress
Conversion Type Type of conversion performed when
converting ASCII data to key strokes
- 0x19 0x19 CRC Flag Enables/disables sending CRC
- 0x1A 0x1A Keyboard SureSwipe Flag
Enables/disables SureSwipe Emulation
for Security Level 2
0x1B Decode Enable Property Allows decoding JIS type 2 cards
0x1C SS JIS Type 2 Property Defines start sentinel on JIS cards
0x1D ES JIS Type 2 Property Defines end sentinel on JIS cards
- 0x1E 0x1E P30 Pre Card String Pre card string
- 0x1F 0x1F P31 Post Card String Post card string
- 0x20 0x20 P32 Pre Track String Pre track string
- 0x21 0x21 P33 Post Track String Post track string
- 0x22 0x22 P34 Termination String Terminating string
- 0x23 0x23 P35 FS Field Separator for additional data
- 0x24 0x24 P36 SS Track 1 ISO ABA Start sentinel char for track 1 – ISO/ABA
- 0x25 0x25 P37 SS Track 2 ISO ABA Start sentinel char for track 2 – ISO/ABA
- 0x26 0x26 P38 SS Track 3 ISO ABA Start sentinel char for track 3 – ISO/ABA
- 0x27 0x27 P39 SS Track 3 AAMVA Start sentinel char for track 3 - AAMVA
- 0x28 0x28 P40 SS Track 2 7BITS
Start sentinel char for track 2 – 7 bit
data
- 0x29 0x29 P41 SS Track 3 7BITS
Start sentinel char for track 3 – 7 bit
data
- 0x2B 0x2B P43 ES End sentinel char for all tracks/formats
- 0x2C 0x2C Format Code
Defines Format Code to be sent with the
message
- 0x2D 0x2D P45 ES Track 1 End sentinel char for track 1
- 0x2E 0x2E P46 ES Track 2 End sentinel char for track 2
