100
00 00 00 00 00 00 00 00 00 00 00 00
844 - 851
Encrypted Session ID (user didn't load, all zeroes)
00 00 00 00 00 00 00 00
852
Track 1 Absolute data length (same as above)
3C
853
Track 2 Absolute data length (same as above)
25
854
Track 3 Absolute data length (same as above)
1F
855
MagnePrint Absolute data length (same as above)
36
Example 4: Keyboard or Serial reader card swipe in Security Level 2, SureSwipe Mode:
This example shows the data received from a KB swipe for a reader at Security
Level 2. All properties are at their defaults making this a SureSwipe format.
Raw KB Data:
Byte Content
0 %B5452300551227189^HOGAN/PAUL ^08043210000000
50 725000000?;5452300551227189=080432100000007250?+51
100 63499080020445=000000000000?
According to the MagneSafe Swipe Reader Technical Reference Manual and
USB KB SureSwipe & USB KB Swipe Reader Technical Reference Manual (99875206)
the KB Data (SureSwipe format) is broken down like this:
[Tk1 SS] [Tk1 Data] [ES] [Tk2 SS] [Tk2 Data] [ES] [Tk3 SS] [Tk3 Data] [ES] [CR]
Each of the Pxx elements has the default value in this configuration, thus we
can reinterpret the format as:
%[Tk1 Data]?;[Tk2 Data]?+[Tk3 Data]?
We can show this as:
%[Tk1 Data]?
;[Tk2 Data]?
+[Tk3 Data]?
And we can fill this template in with the data we received to get:
%B5452300551227189^HOGAN/PAUL ^08043210000000725000000?
;5452300551227189=080432100000007250?
+5163499080020445=000000000000?
This shows the three tracks of data as received.
Example 5: Keyboard or Serial reader card swipe in Security Level 2, Not SureSwipe Mode:
This example shows the data received from a KB swipe for a reader at Security
Level 2 with the SureSwipe property set to 00 (False).
Raw KB Data:
Byte Content
0 %B5452000000007189^HOGAN/PAUL ^08040000000000
50 000000000?;5452000000007189=080400000000000000?+51
