Page 33
Table A-11. Component Value
Component
Model
E3614A
E3615A
E3616A
E3617A
C2
1000UF 25V +-20% AL-ELECTLT
470UF 50V +-20% AL-ELECTLT
330UF 50V +-20% AL-ELECTLT
220UF 100V +-20% AL-ELECTLT
C7,8
39000UF 25V +-20% AL-ELECTLT
12000UF 63V +-20% AL-ELECTLT
5600UF 100V +-20% AL-ELECTLT
2700UF 160V +-20% AL-ELECTLT
C11,16,17,25,26 0.01UF 100V +-10% CER X7R
0.01UF 100V +-10% CER X7R
C12
0.1UF 50V +-10% CER X7R
0.1UF 50V +-10% CER X7R
C18,21,24,27
0.1UF 630V +-10% POLYE-FL
0.1UF 630V +-10% POLYE-FL
C19,22
1000PF 100V +-5% COG
1000PF 100V +-5% COG
C20,23
1UF 50V +-20% AL-ELECTLT
1UF 50V +-20% AL-ELECTLT
C29
0.01UF 100V +-10% CER X7R
0.01UF 100V +-10% CER X7R
0.047UF 100V +-10% POLYP-MET
0.047UF 100V +-10% POLYP-MET
C61
1UF +-10% 250V POLYP-MET
1UF +-10% 250V POLYP-MET
C62
470PF +-5% 100V CER COG
470PF +-5% 100V CER COG
C63,64,65,66
0.012UF +-10% 200V PE-FL
R1,2
0.1 +-1% 5W
0.2 +-1% 5W
0.6 +-5% 5W
1.78 +-1% 5W
R8,9
1K 1% .125W
1K 1% .125W
1K +-5% 1W
1K +-5% 1W
R11
2K +-5% 3W
5K +-5% 3W
27k +-5% 2W
45K +-5% 2W
R12
1K +-1% .125W
1K +-1% .125W
R13
68.1K +-1% .125W
68.1K +-1% .125W
R14,48,52
19.6K +-1% .125W
19.6K +-1% .125W
R15
10K +-1% .125W
10K +-1% .125W
R16
100K +-1% .125W
100K +-1% .125W
R36
7.32K +-1% .125W
6.81K +-1% .125W
8.25K +-1% .125W
9.53K +-1% .125W
R39
7.5K +-1% .125W
7.15K +-1% .125W
8.66K +-1% .125W
10K +-1% .125W
R40
2.43K +-1% .125W
3.09K +-1% .125W
5.23K +-1% .125W
6.81K +-1% .125W
R41
8.06K +-1% .125W
33.2K +-1% .125W
66.5K +-1% .125W
121K +-1% .125W
R42,44,54,56
10 +-1% .125W
10 +-1% .125W
147 +-1% .125W
147 +-1% .125W
R43,55
100 +-1% .125W
100 +-1% .125W
1K +-1% .125W
1K +-1% .125W
R45,57
100 +-1% .125W
100 +-1% .125W
R46,53
10 +-1% .25W
10 +-1% .25W
R47,50
499 +-1% .125W
499 +-1% .125W
R49,51
1.96K +-1% .125W
1.96K +-1% .125W
R58
0.2 +-1% 10W
0.2 +-1% 10W
0.6 +-1% 10W
1.78 +-1% 5W
R59
0.2 +-1% 10W
1.78 +-1% 5W
R60
390 +-5% 3W
1K +-5% 3W
1.52K +-5% 3W
2.6K +-5% 3W
R62
42.2K +-1% .125W
105K +-1% .125W
475K +-1% .125W
825K +-1% .125W
R70
178K +-1% .125W
383K +-1% .125W
23.7K +-1% .125W
100K +-1% .125W
R72
13.3K +-1% .125W
6.19K +-1% .125W
51.1K +-1% .125W
26.1K +-1% .125W
R74,75
12.1K +-1% .125W
12.1K +-1% .125W
20.5 +-1% .125W
17.8K +-1% .125W
R77
21.5 +-1% .125W
21.5 +-1% .125W
56.2 +-1% .125W
56.2 +-1% .125W
R79
147K +-1% .125W
422K +-1% .125W
681K +-1% .125W
1M +-1% .125W
R82
26.1K +-1% .125W
26.1K +-1% .125W
68.1K +-1% .125W
68.1K +-1% .125W
R98
261K +-1% .125W
100K +-1% .125W
68.1K +-1% .125W
31.6K +-1% .125W
R115
75K +-1% .125W
82.5K +-1% .125W
75K +-1% .125W
68.1K +-1% .125W
R116
28K +-1% .125W
38.3K +-1% .125W
38.3K +-1% .125W
35.7K +-1% .125W
R124
1 +-1% .125W
1 +-1% .125W
R125
681K +-1% .125W
681K +-1% .125W
Q1,4
MOSFET N-CHAN E-MODE TO 204AE
MOSFET N-CHAN E-MODE TO 204AE
MOSFET N-CHAN E-MODE TO 3 SI
MOSFET N-CHAN E-MODE TO 3 SI
Q5,8
NPN 2N2222A SI TO-18 PD=500MW2
NPN 2N2222A SI TO-18 PD=500MW
Q6,7
NPN 2N2222A SI TO-18 PD=500MW2
NPN 2N2222A SI TO-18 PD=500MW2
PNP 2N2907A SI TO-18 PD=400MW
PNP 2N2907A SI TO-18 PD=400MW
U2
IC OP AMP GP DUAL 8 PIN DIP-P
IC OP AMP GP DUAL 8 PIN DIP-P
U21,22,23,24
OPTO-ISOLATOR LED-TRIAC
OPTO-ISOLATOR LED-TRIAC
CR3,4,5,6,7
DIODE-GEN PRP 180V 200MA D0-35
DIODE-GEN PRP 180V 200MA D0-35
CR11,14
DIODE-PWR RECT 400V 1A 50NS DO-41 DIODE-PWR RECT 400V 1A 50NS DO-41
T1
TRANSFORMER-POWER FOR E3614A
TRANSFORMER-POWER FOR E3615A
TRANSFORMER-POWER FOR E3616A
TRANSFORMER-POWER FOR E3617A
T2,3
TRANSFORMER-PULSE; PRI IND:5MH
TRANSFORMER-PULSE; PRI IND:5MH
A-19
