EN - English - I
nstruc
tions manual
10
7.2 Operational test
7.2.1 Checking the power supply
Depending on the type of illuminator, ensure that the
supply voltage is within the range.
POWER SUPPLy
Illuminator power supply Range
120-230Vac 10%
24Vac/Vdc 10%
12Vdc 5%
Tab. 5
7.2.2 Checking the photocell’s operation
Verify the photocell functions plugging it with black
tape.
8 Disposal of waste
materials
This symbol mark and recycle system
are applied only to EU countries and not
applied to the countries in the other area of
the world.
Your product is designed and manufactured with
high quality materials and components which can be
recycled and reused.
This symbol means that electrical and electronic
equipment, at their end-of-life, should be disposed of
separately from your household waste.
Please dispose of this equipment at your local
Community waste collection or Recycling centre.
In the European Union there are separate collection
systems for used electrical and electronic products.
9 Technical data
9.1 General
Die cast aluminium body
Supplied complete with horizontal and vertical
rotating support in painted galvanized steel and
painted aluminium
Wavelengths 850, 940 nm
9.2 Mechanical
Dimensions: see drawings
9.3 Electrical
Power supply: 24Vac, 12-24Vdc and 90/240Vac
Consumption: 30W
State of the art SMD LED
Adjustable built-in photocell for automatic activation
and deactivation
Input for activation by means of a volt free relay
contact
Clean contact output (Follow)
Multipolar cable L: 2m (6.56ft)
- Telemetry: 4x0.34mm² (AWG22)
- Power supply 24Vac,12/24Vdc: 2x0.75mm²
(AWG18)
- Power supply 90/240Vac: 3x0.75mm² (AWG18)
9.4 Illuminators
GEKO IRN - BEAM PATTERN AND ACHIEVABLE DISTAN-
CES FOR ONE ILLUMINATOR
Horizontal/
vertical beam
patterns
850nm 940nm
10˚ 240m 140m (460ft)
30˚ 130m 80m (262ft)
60˚ 80m (262ft) 60m (197ft)
Tab. 6 Achievable distance with: BOSCH LTC0620/11 Day/
Night camera. COMPUTAR lens H30Z1015 10-300mm,
F1.5. The typical distance of the subject to illuminate is
in function of the reflection coefficient of the illumina-
ted scene.
9.5 Environment
Indoor / Outdoor
Operating temperature: -50°C/+60°C (with illuminator
on)
IP66/IP67 according to EN60529
9.6 Certifications
Electrical safety: EN60598
Photobiological safety of lamps and lamp systems:
EN 62471
Electromagnetic compatibility: EN55022, Class A
Immunity: EN50130-4
FCC Part 15, Class A
