SECTION 6 GPIB
6-7
6.2.6 Parameter
The table below shows the parameter types employed for this instrument.
In this manual, these parameter types are written in lower-case alphabetical characters between brackets < >, and
the IEEE488.2 (or SCPI)-defined s corresponding to them are written in upper-case alphabetical
characters. The correspondence between each parameter and IEEE488.2 (or SCPI) is written for the various
commands.
Table 6-1. Contents of Parameter Types
Parameter type Description
Represents decimal numbers. A
GRAM> item, such as MINimum or MAXimum, is
included in a special numeric format.
Represents a theoretical value. OFF or 0 corresponds to
FALSE, and ON or 1 corresponds to TRUE. When 0,1 or
(defined by SCPI) OFF, ON are used for setting, queries return 1 or 0, never
ON or OFF.
Represents a character data. It is possible to express a short
character string corresponding to the setting contents. Both
long and short forms can be used.
Non parameter
6.2.7 Unit
The table below shows the unit types employed for this instrument.
In this manual, these unit types are written in lower-case alphabetical characters between brackets < >.
Table 6-2. Contents of Unit Types
Unit type Description
At frequency and FM deviation setting, four units can be use: “Hz”, “kHz”, “MHz”,
“GHz”. Omission of the unit symbol is regarded as “Hz”.
At RF output level and AF output level setting, five units can be use: “dB”, “dBm”,
“dBu”, “V”, “mV”, “uV”. Omission of the unit symbol is regard is regard as “dBm” or
“V”.
At AM depth setting, the unit must be “%” or “PCT”. Omission of the unit symbol is
regard as “%”.
At sweep time setting, three units can be use: “s”, “ms”, “us”. Omission of the unit
symbol is regard as “s”.
Non unit.
