76
DTMF FUNCTIONS
This transceiver provides you with 10 dedicated DTMF
memory channels. You can store a DTMF number (16
digits max.) in each of these channel to recall later for
speed dialing.
Many repeaters in the U.S.A. and Canada offer a
service called Autopatch. You can access the public
telephone network via such a repeater by sending
DTMF tones. For further information, consult your local
repeater reference.
M
ANUAL
D
IALING
(TH-K2AT/ ET/ K4AT
ONLY
)
The numeric keypad functions as a DTMF keypad; the
12 keys found on a touch-tone phone plus 4 additional
keys (A, B, C, D) on the rightmost column.
To perform Manual Dialing, follow the steps below.
1 Press and hold [PTT] to transmit.
2 While transmitting, press the keys in sequence on
the keypad, to send the DTMF tones.
• The corresponding DTMF tones are transmitted and
monitored through the speaker.
. q e r F
) z H (
9 0 2 1 6 3 3 1 7 7 4 1 3 3 6 1
7 9 6 1 2 3 A
0 7 7 4 5 6 B
2 5 8 7 8 9 C
1 4 9 0 # D
