75
• Specifications subject to change without notice.
• Although the effective pixels for the liquid crystal panel is
given as 99.99% or more, 0.01% of pixels may not light or
may light incorrectly.
Audio/ Video section
Maximum output power
: 50 W x 4
Output power (DIN 45324, +B=14.4V)
: 30 W x 4
Speaker Impedance
: 4 – 8 Ω
Tone action
BAND1 (62.5 Hz): ±9 dB
BAND2 (250 Hz): ±9 dB
BAND3 (1 kHz): ±9 dB
BAND4 (4 kHz): ±9 dB
BAND5 (16 kHz): ±9 dB
Preout level / Load (CD/CD-CH)
: 4000 mV/10 kΩ
Preout impedance
: ≤ 600 Ω
iPod terminal
Video output level : 1 Vp-p (75 Ω)
Audio output level : 1.2 V (10 kΩ)
Auxiliary input
Frequency response (±1 dB)
: 20 Hz – 20 kHz
Input Maximum Voltage
: 1200 mV
Input Impedance
: 10 kΩ
General
Operating voltage
: 14.4 V (11 – 16V allowable)
Maximum Current consumption
: 10 A
Installation Size (W x H x D)
: 182 x 53 x 158 mm
Weight
: 1.20 kg
