English | 31
Appendix
For operating KCA-BT300 (Optional)
For operation refer to Model-A in the Instruction
Manual of KCA-BT300, and the table below. The
[AUTO]/[TI] button should be replaced with [SRC]
button for Terminating>.
Set the Type Swith on KCA-BT300 as folllows.
1: OFF, 2: OFF, 3: OFF
Set the remote controller mode switch to “AUD” mode
before starting operation.
Notation used in the KCA-BT300
Instruction Manual Operation
[ 38] button [AUD] knob* 1
Control knob [AUD] knob
[AUTO]/[TI] button [DISP] button
Control knob towards up or down [FM+] or [AM–] button
Control knob towards left or right [ 4] or [¢] button
* 1 Use the [ 38] button for the operation of
Private Mode>.
For operating KCA-BT200 (Optional)
For operation refer to Model-A-1 in the Instruction
Manual of KCA-BT200, and the table below. The
[AUTO]/[TI] button should be replaced with [SRC]
button for Terminating>.
Set the remote controller mode switch to “AUD” mode
before starting operation.
Notation used in the KCA-BT200
Instruction Manual Operation
[ 38] button [AUD] knob* 1
Control knob [AUD] knob
[AUTO]/[TI] button [DISP] button
Control knob towards up or down [FM+] or [AM–] button
Control knob towards left or right [ 4] or [¢] button
* 1 Use the [ 38] button for the operation of
Private Mode>.
Function Glossary
• “AUTO1”, “AUTO2”, “MANUAL” (Tuning mode
select)
Select a tuning mode of the radio.
Tuning mode Display Operation
Auto seek “AUTO1” Automatic search for a station.
Preset station seek “AUTO2” Search in order of the stations in the
Preset memory.
Manual “MANUAL” Normal manual tuning control.
• AUX
When this is set to ON, AUX source can be selected.
ON1: Allows AUX source to be selected. Use this
setting when the built-in AUX terminal is
connected to the external equipment all the
time.
ON2: Activates the attenuator function when
turning on the power with AUX source
selected. Cancel the attenuator function
by turning the volume knob clockwise
when listening to the audio of the external
equipment.
OFF: Disable AUX source selection. Use this setting
when the built-in AUX terminal is not used.
• DTA (Digital Time Alignment)
Make fine adjustment of the delay time of the
speaker output specified at
(page 27) to have a more suitable environment for
your vehicle.
The settings of the delay time are automatically
identified and compensated by specifying the
distances of each speaker from the center of the
vehicle interior.
1 Set the front and rear positions and the height
of the reference point to the position of the ears
of the person sitting in the front seat, and set
the right and left positions to the center of the
vehicle interior.
2 Measure the distances from the reference point
to the speakers.
3 Calculate the distance difference in accordance
with the farthest speaker.
Next page 3
