- 32
MODEL SE 712
ITEM PART NO. REF NO. DESCRIPTION SPECIFICATION
282 301706 0162 Nozzle Cock Support
283 S416 Hex. Socket Head Screw 5/16"x1-1/4"L
284 301534 181202 Knob
284 181202-1 Knob (For CE Only)
285 W005 Washer 1/4"x16xt1.5
286 300739 181201 Blade Back Cover
287 300737 181238 Wheel Cover
288 W005 Washer 1/4"x16xt1.5
289 S701 Cross Round Head Screw 1/4"x1/2"L
290 S201 Cross Round Head Screw 1/4"x1/2"L , For CE Only
291 300960 181237 Motor Pulley Cover ( Plastic )
293 S006 Hex. Head Screw 1/4"x1/2"L
294 W004 Washer 1/4"x19xt1.5
295 300957 K008 Key 5x5x30L
296 S604 Hex. Socket Headless Screw 1/4"x3/8"L
297 300959 181235 Motor Pulley
298 S503 Screw 5/16"x1"L
299 S013 Hex. Socket Head Screw 3/8"x1-1/4"L
300 300741 M301 Motor 3/4HP/110/60/1PH
301374 Motor Fan
301375 Motor Cover
301 S021 Hex. Head Screw 5/16"x2"L
302 N007 Hex. Nut 5/16"
303 301708 181234A Motor Mount Plate
304 N007 Hex. Nut 5/16"
305 43314 S022 Hex. Head Screw 5/16"x3/4"L
306 W016 Washer 5/16"x23xt2
307 301709 181233A Motor Mount Bracket
310 S201 Cross Round Head Screw 1/4"x1/2"L
311 W005 Washer 1/4"x16xt1.5
312 181232-1 Support Plate Optional
313 301486 3055-3 Vertical Saw Table Optional
314 W008 Flat washer 3/8"x25xt2
316 301289 Scale
317 3149 Vent Plug M8xP1
318 3072-2 Bearing Cover
