- 27
MODEL SE 712
ITEM PART NO. REF NO. DESCRIPTION SPECIFICATION
1 300935 181107-2 Swivel Base
2 300757 181108A Acme Screw
3 300907 W002 Washer 1/2"x28xt2
4 300860 S601 Hex. Socket Headless Screw 1/4"x1/2"L
5 300758 181606 Wheel-hand
6 300752 3027-1 Handle
7 301269 181266 Fixed Bolt
8 301270 W008 Flat washer 3/8"x25xt2
9 300936 181114 Vise Jaw Bracket(Front)
10 300937 HP021 Pin
5x34L
11 300938 181136A Bracket
12 300755 181604 Acme Nut
13 300909 181605 Button
14 300910 W203 Spring Washer 3/16" (2 each)
15 300911 191206 Retainer, Spring
16 78833 HS519 Cross Round Head Screw M5x10L
17 43331 S410 Hex. Socket Head Screw 3/8"x1-1/2"L
18 43916 N001 Hex. Nut 1/2"
19 300907 W002 Washer 1/2"x28xt2
20 S501 Carriage Screw 1/2"x2"L
21 S003 Hex. Head Screw 1/2"x2"L
22 300939 181113-1 Vise Jaw Bracket(Rear)
23 300940 181121 Bushing
24 300941 181122-1 Support Rod
25 43314 S022 Hex. Head Screw 5/16"x3/4"L
26 300942 181123 Pivot Bracket
27 181270 Washer
28 S012 Hex. Head Screw 3/8"x1-1/2"L
29 301686 181133 Support Plate
30 181134 Fixed Plate
31 300943 181117-1 Spring or 301290
32 301291 181118 Spring Adjusting Screw
33 301687 181115 Spring Handle Bracket
34 43314 S022 Hex. Head Screw 5/16"x3/4"L
35 43632 W016 Washer 5/16"x23xt2
