- 29
MODEL SE 712
ITEM PART NO. REF NO. DESCRIPTION SPECIFICATION
75 S708 Cross Round Head Screw 3/16"x3/8"L
77 301406 181103 Panel
78 301454 181854 Hose OD16mmxID13mmx260m
82 300962 181256 Coolant Tank
82-1 300961 Filter
84 300754 Pump
85 S701 Cross Round Head Screw 1/4"x1/2"L
86 W004 Washer 1/4"x19xt1.5
88 301694 181852 Coupler 3/8"PT
89 181601 Hose Clip ACC-4( 5)
90 301456 181981 Hose 0D12mmxID8mmx2000m
91 301455 181856 Valve 1/8"PT
94 301535 181128 Wheel Rod
95 300742 181129 Wheel
96 301536 HP210 Cotter Pin
3x25L
97 300730 181304-2 Cylinder Complete Set OR 300750 RF-712N
99 W017 Washer 5/16"x18xt1.5
100 S017 Hex. Head Screw 5/16"x1"L
101 S412 Hex. Socket Head Screw 3/8"x2-1/4"L Threaded
102 W013 Washer 3/8"x20xt2
112 181241BS Brush Assembly items 112-118, 120, 258
113 300952 181242B Brush Support
114 W007 Washer 3/16"x12xt0.8
115 S708 Cross Round Head Screw 3/16"x3/8"L
116 301695 192029 Bearing Spacer
117 301696 181307 Bushing
118 78744 HS422 Hex. Socket Headless Screw M6x10L
119 301620 181241BS Brush assembly items 112-118,120,258
120 300951 192030 Spring for brush
130 181306 Bracket For CE Only
131 HS508 Cross Round Head Screw M4x5L , For CE Only
132 181305 Switch base For CE Only
133 HW003 Washer M5 , For CE Only
134 HW509 Cross Round Head Screw M4x10L , For CE Only
201 300749 181216-1 Gear Box
201 300749R Rebuilt gear box
