Force 40 70 100 Ton
7
Fig. 6
Pump rotation
After making the electrical connections to the press it is necessary to make a visual check on the
direction of rotation of the electric motor.
Before checking the direction of rotation of the pump, fill the reservoir with oil see Fig. 6
1. Unscrew the inspection cap.
2. Identify a reference point on the drive shaft.
3. Power up the motor for Max. 1-2 seconds.
4. Check that the rotation of the shaft coincides with that of the arrow shown on the top of
the unit see Fig 7.
5. Screw down inspection cap.
If the motor rotates in the wrong direction:
See your electrician.
Any damage caused by wrong electrical connection is not covered by warranty
Fig. 7
