11
8. PARTS LIST
10 TON BENCH UTILITY PRESS PARTS LIST
Ref # Dake Part # Description Qty.
1 301139 Frame upright channel 2
2 301138 Head frame channel 2
3 / 19 301137 / 301133 Head ram traverse plates 1 upper & lower
4 301136 Bolt M12 x 110mm 6
5 301135 Lock washer 12mm 6
6 301134 Nut M12 x 4 6
7 301132 Union support 1
8 301131 Base angle 2
9 301130 Bolt M8 x 20 6
10 301129 Lock washer 8mm 6
11 301128 Nut M8 6
12 301127 Flat nose piece 1
13 301126 Step nose piece 1
14 301125 Table pin 2
15 301124 Table plate 2
16 301123 Work table 1
17 301122 Ram / Cylinder 1
18 301121 Pumping unit 1
20 301150 Bolt M10 x 140 2
21 Washer 10mm 2
22 301149 Lock washer 10mm 2
23 301141 Nut 10mm 2
24 301120 Gauge 1
25 Ring 1
Spare seals should be stored in safe location out of direct sunlight if future is
required.
