Pivot bolt must be free to rotate (see photo p-w1), Ders are fully retracted (see photo p-w3) – Summers 50' Superroller User Manual

Page 19

background image

SECTION 2 - ASSEMBLY

2-9

8S3059

PLUG

P-W2

P-W1

P-W3

DO NOT OVER TIGHTEN.

PIVOT BOLT MUST BE FREE TO ROTATE.

CONTACT AREA:

MUST BE FREE

OF DIRT AND DEBRIS
