Jibstick layout and functions – VariZoom VZCINEMAPRO-K4 User Manual
Page 6
Analog lens control connector- White
Digital lens control connector- Gray
Set pan axis soft limits
Set tilt axis soft limits
Analog lens voltage balance
Pan/tilt smoothing
Pan speed
Tilt speed
Joystick for pan and tilt operation
Pan/Tilt/Zoom/Focus Response Direction
Communication Connection
USB connector
Sync
Power
Motor Power
After all connections have been made and the camera is balanced, switch on power located on the
power brick.
After sync is established (the “sync” light on the jibstick should be illuminated), switch on motor power
(See below for location)
2. Jibstick layout and functions
Communication connector- Green
