021-MVP-F Rev A
MVP-F User Manual
5
Copyright © High Country Tek, Inc.
– 2013
MVP-F
Closed-loop Controller
MVP-F Controller
The MVP-F controller drives proportional solenoid valves in a closed loop system to follow a command signal.
When the feedback is greater than the command input, the coil receives full current; when the feedback is less than
the command input, the coil receives no current.
Once configured, the settings are permanently stored in the controller memory.
MVP-F Features
Easily configured using HCT Graphical User Interface (GUI) or HCT Hand Held Interface (HHI)and prewired
18AWG PVC cable
LED indicators for power, output current and fault status
Permanently sealed, standard DIN 43650 Form A connector body
Multiple modes for open loop, closed loop and inverted
Single coil applications, feedback input only for closed-loop applications
All input and output limits are independently adjustable
Adjustable output with short circuit protection, fully adjustable PID control loop
User configurable over and under limit handling
Operating Specifications
Supply Voltage
9 to 28VDC
Supply Current
Valve current + 20mA (Quiescent Max)
Output Current
-06A: 600mA MAX
-12A: 1.2A MAX
-25A: 2.5A MAX
Coil Resistance
2Ω MIN.
Reference Voltages
+5V @ 2mA
Dither Frequency
50, 75, 100, 125, 150, 175, 200, 225, 250, 275, 300, 350, 400, 500, 1000Hz
Analog Input Range
-F1V: 0 to 10V
-F2A: 4 to 20mA
Analog Input Impedance
-F1V: 12K
-F2A: 250
Operating Temperature Range
-20º to 70º C (operating); -40º to 85º C (storage)
Enclosure
Glass filled Nylon
Dimensions
Inch: 2.4 L x 1.2 W x 0.75 H; Mm: 60 L x 30 W x 19 H
