021-MVP-F Rev A

MVP-F User Manual

10

Copyright © High Country Tek, Inc.

– 2013

MVP-F

Closed-loop Controller

Parameter List

The following table outlines the MVP-F parameters as well as the limits and units of measure for each parameter.

Parameter

Limits

Units

MVP-Fxx-xxx

Version #

Mode

See Mode Description

Mode #

Proportional gain

0 to 100

%

Integral gain

0 to 100

%

Derivative gain

0 to 100

%

PID loop time

1 to 30

# cycles

Dither frequency

50, 75, 100, 125, 150, 175, 200, 225, 250, 275,
300, 350, 400, 500, 1000

Hz

Minimum command

0 to 10.0 (0 to 20.0)

V (mA)

Maximum command

0 to 10.0 (0 to 20.0)

V (mA)

Minimum feedback

0 to 10.0 (0 to 20.0)

V (mA)

Maximum feedback

0 to 10.0 (0 to 20.0)

V (mA)

Minimum output

0 to 600

*

mA

Maximum output

0 to 600

*

mA

Command below min

Off, Limit, Fault

Command above max

Off, Limit, Fault

Feedback below min

Off, Normal, Fault

Feedback above max

Off, Normal, Fault

Command

V (mA)

Feedback

V (mA)

Error

Output current

mA

Supply voltage

Volts

Fault status

Fault

*

0 to 1.2A for

–12A version, 0 to 2.5A for –25A version
