Electrical Characteristics

Supply Voltage:

• Range: +8.5Vdc to 32Vdc

• Reverse polarity protection

and transient protection up to
1.5K Watts Peak Pulse Power
Dissipation

• Power is supplied to the

module through Pin 3.

• GROUND is the DVC61

main common (usually
connects to chassis ground),
and is connected to the
module through Pin 4.

Current Consumption:

• Maximum ≅ 0.25 A

(w/ backlight on)

• Maximum ≅ 0.06 A

(w/ backlight off)

Digital Inputs:

• Maximum Voltage Range:

0Vdc to 32 Vdc

• Low: 0Vdc to 0.5Vdc

High: 4.5Vdc to 32Vdc

Environmental Characteristics

Overall:

• Operating Temperature:

-20

°C to 70°C

• Storage Temperature:

-30

°C to 80°C

• Sealed metallic enclosure

designed specifically for
harsh industrial environments
commonly found in mobile
applications.

Connector:

• Water does not penetrate

seals when submerged in 3
feet of water. Meets
requirements of DIN 40050
IP6K9K.

• Provides excellent

vibration/shock reliability
that is required in truck, bus
and off-highway industry.

• Temperature Range:
-55

°C to +125°C
