Face panel description – AMETEK 1746 LDT Interface Card User Manual
Page 5
Chapter 1: Introduction & Overview
Installation & Programming Manual
2
1.1: Face Panel Description
The Monitor’s operating status is indicated by the two (2) LEDs on the face panel.
RUN
The green LED indicates that the card is operational.
FAULT
The red LED indicates there is a card fault, or when there is a resolver
(transducer) fault.
Note: There are four typical causes for a resolver (transducer) fault:
1. Broken resolver cable
2. Improperly wired cable
3. Faulty resolver
4. Non-compatible resolver
INSIDE FACE PANEL DOOR
Plug-in connector with 16 terminals. (See wiring diagrams, Appendix B)
