AMETEK 1980R Rotating Cam Limit Switch w/Resolver - Manual (Page 19)

19 6380 Brockway Road • Peck, MI 48017 • 800.325.8074 • 810.378.5511 • Fax 810.378.5516 • www.AMETEKAPT.com
2.66 REF
2.00
G .38 D
C
.25
B
2.45
E
F
3.25
Y
2.88
2.00
NOTE: Intrusion below baseline in positions
R2, R5, L5, or L8
.43
.94
1.78
A-R
.38
(4 MTG HOLES)
CONDUIT FITTING ON END
OPPOSITE GEAR REDUCER
L
2.00
1.50
.75
#606
WOODRUFF
KEY
.7490
.7475
GROOVES TO ACCEPT
GEMCO ADJ. COUPLING
.50
1.50
.4975
.4995
#404 WOODRUFF KEY
2.88
NOTE:
ASSEMBLY SHOWN IS STANDARD.
REDUCER CAN BE PLACED ON EITHER END. SHAFT
EXTENSION ON END OPPOSITE OF REDUCER IS OPTIONAL.
5.44
Dia.
Dia.
Dia.
CONDUIT FITTING
ON END OPPOSITE
SHAFT EXTENSION
3.25
F
E
2.45
L
B
.25
C
D
G
5.44
1.50
.50
.4995
.4975
#404 WOODRUFF
KEY
GROOVES TO
ACCEPT GEMCO
ADJ. COUPLING
2.66 REF
A-S
Y
X
.38
.7490
.7475
.75
#606
WOODRUFF
KEY
1.50
.38
(4 MTG HOLES)
MIN. VERTICAL
CLEARANCE TO
REMOVE COVER
.50 TYP
10.38
NOTE:
ASSEMBLY SHOWN IS STANDARD.
REDUCER CAN BE PLACED ON EITHER END. SHAFT
EXTENSION ON END OPPOSITE OF REDUCER IS OPTIONAL.
Dia.
Dia.
Dia.
NEMA 12 with Straight Drive Gear Reducer
NEMA 12 with Right Angle Gear Reducer
