Operating and installation instructions
CONA
®
SC/SC-Plus - Ball float steam traps
7.5 Tightening torques
(refer to Fig. 1 page 4 - Fig. 10 page 11)
8.0 Troubleshooting
In the event of malfunction or faulty operating performance check that the installation and
adjustment work has been carried out and completed in accordance with these Operating
Instructions.
If malfunctions cannot be eliminate with the help of the following table
“9.0 Troubleshooting table”, the supplier or manufacturer should be consulted.
Pos.
CONA SC PN16/25/40
CONA SC-Plus PN16/40
Torque (Nm)
CONA SC
DN15-25
CONA SC-Plus
DN25
8 Strainer plug 70 --
24 Controller 60 100
27 Cheese head screw M10/M12 PN16/25 = 15
PN40 = 20
PN16 = 25
PN40 = 30
47 Plug 50
50 Plug 50
51 Manual ari vent valve 50
51.1 Pressure screw 30
52 Union for pressur compension line 50
56 Ball valve for blow down valve 50
-
ATTENTION !
- It is essential that the safety regulations are observed when identifying faults.
