WIRELESS INTERFACE

AT&T LTE with fall back to HSPA and EDGE (coming soon)

Bell Mobility LTE with fall back to HSPA (coming soon)

Verizon LTE with fallback to EVDO (coming soon)

Dual-band CDMA2000 EVDO Rev. A (backward compatible with 1xRTT)

GSM HSPA (backward compatible with EDGE)

EDGE/GPRS

PROGRAMMABLE PLATFORM

Software Development Kit (SDK)

C/C++/Perl

PROTOCOL GATEWAY

I/O controller

Modbus RTU/TCP/ASCII/RTU

DNP3 – slave

SYSTEM PERFORMANCE

32-bit ARM9 400 MHz CPU

512 MB NAND Memory

128 MB RAM

TUNNELING

IPsec and SSL

IP

NAT, port forwarding, dynamic DNS, DHCP

Stateful inspection firewall, IP transparency

GPS

GNSS supported: GPS L1, GLONASS L1, Galileo E1

High RF sensitivity plus Jamming detection/removal

ETHERNET INTERFACE (10/100 AUTO-SENSING)

1x or 2x RJ45

WAN capability on 2nd port

SERIAL INTERFACE

1x RS232 Serial DB9 115200bps

1x RS485 Serial Screws 115200bps

USB INTERFACE

1x USB 2.0 Device mini

1x USB 2.0 Host type A

INPUTS & OUTPUTS

2 digital input

2 digital output

3 analog input

1 relay output

See detailed I/O specifications

RAM 9000 Specifications

POWER INPUT

Range: 8-30 VDC (12 or 24 VDC nominal)

Power consumption: (less DO power)

Idle: 6 W (0.25A at 24VDC)

Typical: 8 W (0.33A at 24 VDC)

Peak: 11 W (0.46A at 24VDC)

Power consumption of DO: (max. each)

30 W (1A at 30 VDC)

Heat dissipation: 38 BTU/hour max

MECHANICAL

Dimensions: 132H x 127D x 70W mm (5.2” x 5.00” x 2.75”)

Material: Steel with black zinc coating

Weight: 906 g (2 lbs)

ENVIRONMENTAL

Operating temperature: -40° to +75°C*

Shock: IEC60068-2-27

Vibration: IEC60068-2-6

Humidity: 5 to 95% non-condensing

CERTIFICATION

EMI/EMC:

Emissions: FCC, Part 15 and Industry Canada, ICES-003; Class A;

EN55022, IEC61000-6-4

Immunity: IEC61000-6-2 (EN61000-4-2,3,4,5,6,8)

Hazardous locations: Class I, Div. 2, Groups A, B, C, D, ISA 12.12.01

Electrical safety: UL508/CSA22.2/14 (CUL); IEC61010-1

Carrier specific approvals (Contact Red Lion for latest)

RoHS compliant

WARRANTY

3 years on design and manufacturing defects

* See details in user manual regarding temperature ratings for short and long

term operation. Short term operation can support temperatures up to +75°C.

ORDERING GUIDE

PART NUMBER

DESCRIPTION

RAM-9701-GE

Generic LTE, 1 Ethernet port

RAM-9711-GE

Generic LTE, 2 Ethernet ports

RAM-9701-AT

AT&T LTE, 1 Ethernet port (available soon)

RAM-9711-AT

AT&T LTE, 2 Ethernet ports (available soon)
