Translating Configurations
Introduction
Stop Nut
Secondary
Guide
Anti-Rotation
Key Adaptor*
Drive Shaft
Gearbox
Motor Adaptor
Rod End
Clevis End
Top Plate
Bellows Boot
Rotary Limit
Switch Adaptor
Rotary Limit Switch
Brake
Hand Wheel
Protection Cap
Encoder
Fork End
Electric Motor with or without:
•
Brake
•
Encoder
•
Forced Ventilation
Lead Screw Options:
1.
Standard 1 x Pitch
2.
2 x Pitch
3.
Anti-Rotation (Keyed)
4.
Stainless Steel
5.
Left Hand Thread
Coupling
Limit Switches
Trunnion Feet
Trunnion
1
2
3
4
5
* For use with Anti-Backlash and some safety nut models only.
Upright
Inverted
Available as:
1.
Standard
2.
Anti-Backlah
3.
Anti-Rotation (Keyed)
4.
Safety Nut
