Chapter 7 ____________________________________________________________ Technical Data
VAISALA _______________________________________________________________________ 59
CHAPTER 7
TECHNICAL DATA
This chapter provides the technical data of the SHM40 kit.
Specifications
Table 8 HMP40S Probe
Property Description / Value
Relative humidity
Measurement range 0 ... 100 %RH
Accuracy (incl. non-linearity, hysteresis
and repeatability)
Temperature range 0 ... +40 °C
0 ... 90 %RH ±1.7 %RH
90 ... 100 %RH ±2.5 %RH
Temperature range
-40…0 °C, +40…+80 °C
0 ... 90 %RH ±3.0 %RH
90 ... 100 %RH ±4.0 %RH
Factory calibration uncertainty at +20 °C ±1.5 %RH
Humidity sensor Vaisala HUMICAP® 180R
Stability ±2%RH over 2 years
Typical stabilization time in a borehole
when the concrete and the probe are in the
same temperature
30 min
Temperature
Measurement range -40…+80 °C
Accuracy over temperature range
0…+40 °C ±0.2 °C
-40…0 °C, +40…+80 °C ±0.4 °C
Temperature sensor Pt1000 RTD 1/3, Class B IEC 751
General
Operating temperature range for probe -40 °C...+80 °C
Probe diameter 12 mm
Probe length 71 mm
Cable length (standard cable) 0.3 m
Cable length (long cable) 2.7 m
Probe weight with standard cable 31 g
Probe housing material Stainless steel
Probe filter and sensor protection Membrane filter with
chrome coated ABS plastic
