-1-

OPERATING INSTRUCTIONS

1

1

1

1

1

ON-OFF POWER BUTTON

Press this button to turn the unit on or off.

2

2

2

2

2

VOLUME/LEVEL CONTROL

To increase the volume level, press the

side of the control.

The volume will increase and the level will be shown on the
display panel from a minimum of 0 to a maximum of 15. To
increase the volume quickly, keep the button pressed. To
decrease the volume level, press the

side of the control. Keep

the button pressed to decrease the volume quickly. This control
is also used in conjunction with the Select button

3

to adjust the

bass, treble, balance and fader levels as described in

4

,

5

,

6

,

and

7

.

3

3

3

3

3

SELECT BUTTON (SEL)

This button is used to select the audio function (bass, treble,
balance, or fade) to be adjusted using the Level control

2

.

Pressing the Select button once will set the unit for volume
adjustment ( VOL will appear on the display panel). Pressing the
button additional times will select bass adjustment ( BAS on
display), treble ( TRE ), balance ( BAL ), or fader ( FAd ). The
display will automatically return to the normal indication 5 seconds
after the last adjustment or when another function is activated.

4

4

4

4

4

BASS CONTROL

To adjust the bass level, first select the Bass mode by pressing
the Select button

3

so the BAS indication appears on the

display panel. Within 5 seconds of choosing the Bass mode,
press the

or

side of the Level control

2

to adjust the bass

response as desired. The level will be shown on the display
panel from a minimum -10 to a maximum of 10 (0 indicates flat
response). The display will automatically return to the normal
indication 5 seconds after the last adjustment or when another
function is activated.
