A.R.I. K-010 EN - Manual

Installation and Maintenance of
A.R.I.’s K-010 /K-012/K-014
Kinetic Air Valves
A. Installation
A.1 The air valve will be mounted on a riser,
connected to the top of the pipe.
A.2 An isolating valve will be installed below the air
valve.
C. Basic, Periodic, Maintenance
B.1 Shut the isolating valve below the air valve.
B.2 Unscrew the bolts (2) that connect the valve cover (4) to the body (1).
B.3 Wash the body and the cover and in clean water in order to remove coarse grime or
accumulated scale. Check if the seal, the seat, or the float are dirty, and clean them.
B.4 Reinstall in reverse order and fasten and tighten all bolts. Make sure to re-assemble
the components correctly:
B.5 Open the isolating valve beneath the air valve.
