31
TR
R
L

TL

Selecting Correct Clamping Unit Configuration
Single version also left hand
Single version also right hand
Left hand for clockw
ise
Right hand for cou
nter
clockwise (anti clock
wise)
Right-hand cutting unit
Left-hand cutting unit
Right hand clamping unit
Left hand clamping unit
Clockwise spindle rotation (M04)
Anti-clockwise spindle rotation (M03)
