External – OD turning

Cx-TRE-xxxxA

Single external

Cx-TRE-xxxxA-DT

Double for sub

spindle

Cx-TRE-xxxxA-YT

Y axis

Cx-TRE-xxxxA-TT

Half Turret

APB-TNE-xxxxA-25

Parting blade

adaptor

Cx-TRI-xxxxA

Single internal

Cx-TRI-xxxxA-SS

Sub spindle

Cx-TRI-xxxxA-DT

Double for sub

spindle

Cx-TRI-xxxxA-YT

Y axis

Cx-TRI-xxxxA-TT

Half Turret

Internal – ID turning/drilling

Driven

Cx-DTE-xxxxA-E/I

External

Cx-DTI-xxxxA-E/I

Internal

Cx-DTI-xxxxA-DTE/I

Double internal

E = External coolant

I = Internal coolant
