Pure PocketDAB 2000 - User Guide - Manual (Page 6)

3
Optical
Digital output
of DAB or MP3
or analogue
output
3.5 mm
headphone
socket
Vol -/+
Volume jog dial.
Push in to mute
Power
Hold down for 2
seconds to
turn on or off
Lock
Slide to lock
buttons preventing
accidental presses
USB
Connector for
software upgrades
and file transfer
SD card slot
For removable
MP3 storage
5.7 V DC
Socket for
power adapter
Battery
compartment
Slide cover
down and
insert 3 AA
batteries
Optical
- V
ol +
Powe
r
Lock
5.7 V DC
