900-0127-01-00 Rev D 19
Specifications
Table 3 EnergyCell Battery Electrical Specifications
EnergyCell RE (all models) EnergyCell GH (all models)
Battery Category Valve-regulated, lead-acid (VRLA) Valve-regulated, lead-acid (VRLA)
Battery Technology Absorbed glass-mat (AGM) Absorbed glass-mat (AGM)
Cells Per Unit 6 6
Voltage Per Unit (nominal) 12 Vdc 12 Vdc
Operating Temperature Range
(with temperature compensation)
Discharge: -40°F (-40°C) to 160°F (71°C)
Charge: -10°F (-23°C) to 140°F (60°C)
-40°F (-40°C) to 122°F (50°C)
Optimal Operating
Temperature Range
74°F (23°C) to 80°F (27°C) 50°F (10°C) to 104°F (40°C)
Self-Discharge
Store up to 6 months at 77°F (25°C)
before a freshening charge is required.
Store up to 18 months at 77°F (25°C)
before a freshening charge is required.
Table 4 EnergyCell Front Terminal Mechanical Specifications
170RE 200RE 200GH 220GH
Terminal
Threaded insert terminal to accept
¼”-20 UNC bolt
Threaded stud to accept M6 nut
Terminal Hardware Initial Torque 110 in-lb (12.4 Nm) 80 in-lb (9.0 Nm)
Weight 115.0 lb (52.2 kg) 131.0 lb (59.4 kg) 115.7 lb (52.5 kg) 132.3 lb (52.5 kg)
Dimensions (H x L x W)
11.1 x 22.1 x 4.9”
(28.3 x 56.1 x
12.5 cm)
12.6 x 22.0 x 4.9”
(32.0 x 55.9 x
12.5 cm)
11.1 x 22.1 x 4.9”
(28.3 x 56.1 x
12.5 cm)
12.4 x 22.1 x 4.9”
(31.6 x 56.1 x
12.5 cm)
Table 5 EnergyCell Top Terminal Mechanical Specifications
34RE 52RE 78RE 95RE 106RE
Terminal
Threaded insert terminal to
accept 10”-32 UNC bolt
Threaded insert terminal to accept ¼”-20 UNC bolt
Terminal Hardware Initial Torque 30 in-lb (3.4 Nm) 110 in-lb (12.4 Nm)
Weight 27 lb (12.2 kg) 40 lb (18.1 kg) 54 lb (24.5 kg) 64 lb (29.0 kg) 69 lb (31.3 kg)
Dimensions (H x L x W)
6.8 x 7.8 x 5.2”
(17.3 x 19.7 x
13.2 cm)
8.1 x 9.0 x 5.5”
(20.5 x 22.9 x
13.9 cm)
8.0 x 10.8 x 6.8”
(20.3 x 27.3 x
17.3 cm)
8.1 x 12.5 x 6.8”
(20.5 x 31.8 x
17.3 cm)
8.5 x 13.4 x 6.8”
(21.6 x 34.1 x
17.3 cm)
Table 6 EnergyCell Charging Requirements at 77°F (25°C)
34RE 52RE 78RE 95RE 106RE 170RE 200RE 200GH 220GH
Recommended Maximum
Current Limit Per String
7 Adc 10 Adc 15 Adc 18 Adc 20 Adc 25 Adc 30 Adc 32 Adc 36 Adc
Float Charging Voltage 13.5 to 13.8 Vdc 13.62 to 13.8 vdc 13.62 Vdc
Absorb Charging Voltage 14.4 to 14.8 Vdc 14.4 Vdc
Temperature
Compensation Factor
0.03 Vdc per battery in series (5 mV per cell) per degree C
0.024 Vdc per battery
in series (4 mV per
cell) per degree C
