Dee Zee DZ1361 - Manual (Page 3)

BD 1360 L/R 1 LH / 1 RH GSK-15 6 FT. MUDFLAP 1 LH / 1 RH B 1648LP X2
B 1648RP X2 B 865 X2 B 885 X2 PN 72 X 36
1/4" FLAT WASHER
E F G H
LEFT BRACKET
1/4" HEX NUT SHEET
METAL SCREW
1/4 X 1" RIBNECK
Dee Zee Brite Tread Side Box Board Installation Instruction
DZ 1361 (2011 - Current) Chevy Dually Pickup
SIDE BOX BOARD RUBBER TRIM MUD FLAP RIGHT BRACKET
A B C D
CARRIAGE BOLT
1/4 X 1" HEX
HEAD BOLT
L
9" ANGLE BRACE 13.5" ANGLE BRACE
I J K
PN 71 X20 PN 97 X2 PN 87 X8 PN 96 X12
PHB 196 X2 PN 836 X2 PN 325 X2
BENT SPACER
N O
8mm X 40mm BOLT 8mm WASHER
M
DZ 1361 1 OF 9 5/23/2011
