Dee Zee FX31930 - Manual (Page 4)

WRENCH/RATCHET
3/8", 7/16"
13mm, 15mm
TIN SNIPS
1/8"
DRILL BIT
Place the bulb-seal gasket [E] onto the backlip of the runing board [A]. Cut the bulb-seal gasket
with tin snips so that it is flush with the ends of the board
FOR REGULAR CAB:
Slide two 1/4 x 3/4" slotted hex head bolts [P] into both of the bolt channels on the bottom
side of the running board.
FOR QUAD, CREW, AND MEGA CAB:
Slide three 1/4 x 3/4" slotted hex head bolts [P] into both of the bolt channels on the bottom
side of the running board.
TOOLS REQUIRED
1
FX 31927 2 OF 10 12/16/2011
