*** TUBES SOLD SEPARATELY
X2 X3
X3
X2 X12 X2 X6
FROM TUBE FROM TUBE
BOLT PACK X12 BOLT PACK X12
6" OVAL SIDE STEP INSTALLTION 6" OVAL SIDE STEP INSTALLTION 6" OVAL SIDE STEP INSTALLTION 6" OVAL SIDE STEP INSTALLTION
DZ 16335 DODGE RAM 1500 2009-2012 - 2500/3500 2010-2012 DZ 16335 DODGE RAM 1500 2009-2012 - 2500/3500 2010-2012 DZ 16335 DODGE RAM 1500 2009-2012 - 2500/3500 2010-2012 DZ 16335 DODGE RAM 1500 2009-2012 - 2500/3500 2010-2012
SIDE STEP TUBE LEFT HAND BRACKET
A B
C
D E F
H I
RIGHT HAND BRACKET
G
1/4" X 1" SHEET
METAL SCREW
8mm X 25mm
FLANGE HEAD BOLT
NUTSERT SET TOOL 8mm HEX
NUTSERT
FLANGE HEAD BOLT
8mm X 20mm 8mm U-NUT
1 of 8 7/10/2013
