4
H.264 Realtime DVR – QUICK USER GUIDE
1.Power : Power ON/OFF
2. Rec : Start & Stop Recording
3.ⓞ~⑨:Key for figure and character
4. P/T/Z: Entering PTZ menu directly
5. OSD : Operating OSD ON/OFF
6. SEQ : Direct access for Spot
7. LOG : Direct access for Log list
8. INFO: Direct access for system Info.
9. ID : Remote controller ID setting
10. MUTE : Audio Mute
11. AUDIO : Available audio switching when user select this key
12. MENU : Entering system menu
13. SEARCH : Entering search
14. ARROW & SPLIT : Key moving left, right, up and down. Also, Screen
split display shows
15. VOL”+,-“ : Up, down volume
16. CH “+,-“ : Up, down channel(s)
17. ▶(▶) : Play(or fast forward)
18. ◀ (◀ ) : Reverse play
19 II : Pause
20. █ : Stopping playback
21. Cam : Changing PTZ icon
22. P/T : Pan &Tilt
23. Z/F : Zoom/ & Focus
24. DIS : Channel Division
DEFAULT PASSWORDS
Front Panel
A Password is required if you need to: enter the menus; search; down
power; playback; stop recording or changing an IP setting.
A prompt will be displayed asking for password.
The default Password is: 00000000 (8 zeros)
Viewer Software
When using the supplied Viewer software, the following password will be required.
User ID is “admin” (not case sensitive).
Password is “00000000” i.e. 8x Zero’s
(Admin ID cannot be changed, as this is the full
administrator ID)
IR Remote Controller
