Flaming River Nova Rack and Pinion Cradle Kits 1962-67 User Manual

Page 2

background image

Page 1 of 10

Modified on 18 Feb 08

JJ/RD/RP/BC

INDEX

NOTE: Before beginning you must first measure the width of your front end from LEFT outer tie
rod end zirc to the RIGHT outer tie rod end zirc to determine the overall width of your front end.
Write dimension here for further reference

NOTE: Part number ES381RL 68-69 Camaro Outer Tie Rod Ends must be used

with this rack and pinion kit.

Parts Inventory

PG 3

Original Column & Wheel Removal

PG 4

Steering Box & Linkage Removal

PG 4

Installation of New Flaming River Tilt Column

PG 5

Electrical System Notes

PG 6

Installation of Rack and Cradle

PG 7

Universal Joint and Steering Shaft Installation

PG 8

Steering Wheel Installation

PG 9

Power Steering Bleeding Procedure

PG 10

Power Steering Valve Diagram

PG 10

Torque Specs

PG 10

Note: For safety disconnect battery cables and ensure that vehicle is properly supported by jack
stands.

We recommend a professional alignment to set the proper alignment settings after system
installation.

We recommend that you always install new outer tie rod ends when installing this kit.

Warranty Disclaimer
Because of their intended usage, the manufacturer makes no warranties whatsoever express or
implied, oral or written, to purchasers of their products regarding performance, safety, fit
merchantability, or length of service. Purchasers are responsible for selection of proper goods and
must rely on there own skill or judgment that such goods are suitable for purchasers application.
