11
NOTE: If you get an Operating Error message, make sure the DLC adapter cable is
securely attached, and the ignition key is ON, then try again. If the problem
remains, refer to Section 4: On-Line Help and Trouble-Shooting Tips.
If any of these tests indicate a fault, the DTCs
will be displayed in the same format as Read
Codes. The tester will display codes similar to
trouble codes. Press the DOWN arrow to view
the pending code(s).
A DOWN arrow displayed on the right of the screen indicates additional codes can
be found on the next screens. Use the DOWN arrow key to view the codes stored in
memory. The last screen will just have
a ] symbol in the last column of the display.
This indicates no more codes are available.
Use the UP arrow key to view the previous
codes.
Use the BACK key to return to the OBD II Function Menu.
Erase Codes
The Erase Codes function is used to erase the trouble codes from the test vehicle’s
PCM. This function also erases freeze frame data, O2 sensor test data, and on-board
monitoring test results, and resets the system monitors to the “Not Ready” status.
Because of this you should erase codes only after you have checked the systems
completely. Erase Codes should be performed at Key On, Engine Off to properly clear
the PCM.
To Erase Codes from your vehicles on-board
computer, select Erase Codes from the OBDII
Function Menu.
A confirmation screen will be displayed to verify
that you wish to erase codes. Select YES to
erase the diagnostic results from the PCM or
NO to cancel and retain the data.
If YES is selected, press the ENTER key and a
message to “Turn ignition key ON, engine
OFF” will display. Press the ENTER to con-
tinue. A “Command Sent” message is mo-
mentarily displayed before returning to the
OBD II Function Menu.
NOTE: If you choose “No”, a Command Cancelled message appears. “Hard” codes,
are trouble codes that will remain in the vehicle’s PCM memory until the
condition is repaired.
NOTE: If you get an Operating Error message, make sure the DLC adapter cable is
securely attached, and the ignition key is ON, then try again. If the problem
remains, refer to Section 4: On-Line Help and Trouble-Shooting Tips.
OBDII FUNCTION MENU
1)Read Codes
2)Pending Codes [
`3)Erase Codes |
Codes Found: 2
Use [ To View Codes
Write Down Codes [
For Reference.
P0123
TP Sensor Circuit
High Input [
Erase Codes And
Diagnostic Results?
Are You Sure?
No
Command Sent
Press A Key to Cont
