XIGMATEK Bifrost-II VD1065 User Manual
XIGMATEK Computer Accessories

2011 © XIGMATEK Co., Ltd. All rights reserved. All trademarks are the property of their respective owners.
http://www.xigmatek.com
E-mail: [email protected] • [email protected]
VGA CARD COMPATIBLE
COMPONENTS
1
4
5
6
7
8
9
10
11
12
13
14
15
16
17
2
3
Small MOS HS
Short
Thermal Paste*3
Thermal Paste*6
NVIDIA GTX470
NVIDIA GTX465
NVIDIA GTX460
NVIDIA GTX580
NVIDIA GTX260
Long Bilt*5 for
NVIDIA GTX280
NVIDIA GTX260
Short Bolt*5
Small Thermal
Paste*8
NVIO 2
core frame
RAM
HSs*14
Buckle*5
ø8 Black
washer*5
ø9 Washer*5
ø7 Washer*5
MOS HS
GPU Cooler
NVIO 2 HS
61mm
Mounting
holes
50.9 X 61 mm
Mounting
holes
58 mm
Mounting
holes
53mm
Mounting
holes
51 mm
Mounting
holes
43 mm
Mounting
holes
ATI Radeon
HD 6870
HD 6850
HD 5870
HD 5850
HD 5830
HD 5770
HD 5750
HD 5670
HD 4890
HD 4870
HD 4860
HD 4850
HD 4830
HD 4750
HD 4670
HD 4650
HD 3870
HD 3850
NVIDIA
GTX 580
GTX 480
GTX 470
GTX 465
GTX 460
GTX 450
GTX 285
GTX 280
GTX 275
GTX 260
GTS 250
9800GT
9600GT
9600GSO
9500GT
Installation of the NVIO 2HS
Buckle
Buckle
NVIO
2HS
MOS
HS
NVIO 2 core frame
Small Thermal Paste
Small MOS HS
or
Installation of the MOS HS and Small Mos HS
Tear the film off from
the Small Thermal Paste:
Installation of the Thermal Paste and RAM hs
Tear the film
off from the
Thermal Paste:
Tear the
film off
from the
RAM hs:
Nipple
Bolt
Thermal Paste
ø7 Washer
INSTALLATION OF THE COOLER
ø9 Washer
ø9 washer is for cores 2.3mm of height,
Please use “ø8 Black Washer” if you’re
working with Nvidia GTX280, 260 and
cores 1.8mm of height.
FEATURES
• Heat-Pipe Direct Touch technology
• 5pcs Φ6mm high performance Heat-pipe
• Plating Black-Nickel on whole body.
• Valuable transparent fan and fan cover
• Application for nVIDIA GTX 580/480, 9800 & 9600 series
• Compatible to ATI 6870/6850/5870/5850 series
• Light weight
• 2pcs 100mm highly efficient fan
• Efficient air flow to cool down components around GPU
HEAT-PIPE DIRECT TOUCH
VGA Cooler
Family
