© TELENAV 2003-5 PAGE 11 OF 31
7. Vehicle Installation
Phone Holder
FOR SAFETY REASONS, WE STRONGLY SUGGEST USING A PHONE HOLDER TO
PLACE THE PHONE AT EYE LEVEL SO YOU CAN QUICKLY SEE THE SCREEN WHEN
NEEDED.
Follow this step only if you’ve purchased a phone holder.
Bend the phone holder into a shape that will place the magnetic holder at a comfortable viewing level,
but will not obstruct driving visibility. If possible, try bending the flexible arm into an “S”-pattern with the
bottom of the arm resting on the dashboard as shown below.
Peel off the protective paper on the suction cup, position the cup onto windshield and flip the lever up
towards the glass to create locking suction.
Use the cleaning pad to clean your phone’s battery cover on the back of the phone. Allow the cleaner
to dry completely before attaching the metal plate to the lower part of the battery cover. Peel the
protective material off of the plate, and then press it firmly in place.
NOTE – on the i90c and i95cl it is VERY important that you mount the metal plate as LOW on
the back cover as possible as shown in the TeleNav GPS Kit diagram. This is because these
phones sense a magnet in the display to determine that the phone is closed. If the metal plate
is too high, the phone holder magnet will confuse the phone into thinking that the cover is
closed, suspend the application, etc.
When parking the phone on the magnetic holder, try to place the phone as HIGH on the holder as
possible to avoid the problem described above.
GPS Receiver
Follow this step only if you’ve purchased a TeleNav GPS Kit.
Place the TeleNav GPS receiver on the dashboard as close to the windshield as possible so that it has
a clear view of the open sky so it can easily receive the GPS signals from space. The GPS satellites
move across the sky, so some of the signals will come from overhead, some from close to the horizon,
and the rest in between.
If your dashboard is sloped, clip the clothespin on the suction cup to the cable near the receiver, and
press the suction cup against the windshield to keep the GPS receiver from sliding around.
